Large
conference and convention installations come with unique wireless challenges.
ULX-D® Digital Wireless is the trusted and reliable partner for secure,
scalable and durable performance, campus-wide. With expanded wide-tuning
frequency bands and up to a 40% increase in rechargeable battery run-time,
ULX-D Wireless provides intelligent solutions for installations and event
requirements of all sizes.
For higher
channel counts in high-tier applications, the ANX4 Scalable Wireless
Receiver receives up to 24 channels of Shure ULX-D wireless audio in a
single rack space. Choose ANX4 to maximise use of your budget, rack space, and
rack weight.
Trusted
reliability. Expanded efficiency. Ready for more
Uncompromising Digital Wireless Audio
24-bit/48 kHz digital audio
that delivers incredibly clear and accurate reproduction of the source
material
20 Hz – 20 kHz frequency range
with flat response
Greater than 120 dB dynamic
range through the analog outputs
130 dB dynamic range (typical)
using Dante and AES67 digital networked audio
60 dB of adjustable system gain
easily accessible from the receiver front panel
No transmitter gain adjustments
needed: optimised for any input source
Wide selection of trusted Shure
Microphones
Extremely
Efficient and Reliable RF Performance
Expanded tuning range - ULXD1,
ULX2, ULXD4D and ULXD4Q components now available with up to 166 MHz
overall tuning range (region dependent)*
Up to 17 active transmitters in
one 6 MHz TV channel (23 on an 8 MHz TV channel)
High Density mode enables up to
47 active transmitters in one 6 MHz TV channel (63 in one 8 MHz TV
channel), with no audio quality degradation
Rock-solid signal stability
with no audio artifacts over the entire 100 meter line-of-sight range
using standard supplied ½ wave antennas
Selectable 1, 10, and 20 mW
transmitter RF output power (comparable to 5 times the analog RF output
power equivalent)
For ease of use, optimised
scanning automatically finds, prioritises, and selects the cleanest
frequencies available.
*Note that
ULXD4, ULXD6 and ULXD8 remain available for operation on legacy frequency bands
Scalable, Intelligent Hardware
Single (half-rack), Dual, and
Quad (full-rack) receiver form factors for any size installation
AES-256 bit encryption equipped
for secure wireless transmission
Ethernet networking allows for
streamlined setup across multiple receivers.
Wireless Workbench 6: The ULX-D
is compatible with Wireless Workbench 6 software for advanced frequency
coordination, monitoring, and control.
Comprehensive 3rd party control
and monitoring across subnets
AXT600
Axient® Spectrum Manager compatibility
Rugged metal housing on both
transmitters and receiver
Dual and Quad receivers
additionally feature:
Expanded tuning range (up to
166 MHz, region dependent)
RF cascade ports, internal
power supply, and dual Ethernet ports
Dante™ digital networked audio
over Ethernet
Bodypack frequency diversity
ensures uninterrupted audio for mission-critical applications
Audio summing routes audio
signal to multiple outputs
Shure Advanced Power Management
SB900 Series rechargeable
batteries provides ULX-D transmitters with up to 12 hours of run-time use
Lithium-Ion chemistry and
intelligent Shure battery circuitry for precision metering and zero memory
effect saving the equivalent of 1000 disposable batteries
Transmitters and receivers
display remaining battery life in hours and minutes, accurate to within 15
minutes.
Large
conference and convention installations come with unique wireless challenges.
ULX-D® Digital Wireless is the trusted and reliable partner for secure,
scalable and durable performance, campus-wide. With expanded wide-tuning
frequency bands and up to a 40% increase in rechargeable battery run-time,
ULX-D Wireless provides intelligent solutions for installations and event
requirements of all sizes.
For higher
channel counts in high-tier applications, the ANX4 Scalable Wireless
Receiver receives up to 24 channels of Shure ULX-D wireless audio in a
single rack space. Choose ANX4 to maximise use of your budget, rack space, and
rack weight.
Trusted
reliability. Expanded efficiency. Ready for more
Uncompromising Digital Wireless Audio
24-bit/48 kHz digital audio
that delivers incredibly clear and accurate reproduction of the source
material
20 Hz – 20 kHz frequency range
with flat response
Greater than 120 dB dynamic
range through the analog outputs
130 dB dynamic range (typical)
using Dante and AES67 digital networked audio
60 dB of adjustable system gain
easily accessible from the receiver front panel
No transmitter gain adjustments
needed: optimised for any input source
Wide selection of trusted Shure
Microphones
Extremely
Efficient and Reliable RF Performance
Expanded tuning range - ULXD1,
ULX2, ULXD4D and ULXD4Q components now available with up to 166 MHz
overall tuning range (region dependent)*
Up to 17 active transmitters in
one 6 MHz TV channel (23 on an 8 MHz TV channel)
High Density mode enables up to
47 active transmitters in one 6 MHz TV channel (63 in one 8 MHz TV
channel), with no audio quality degradation
Rock-solid signal stability
with no audio artifacts over the entire 100 meter line-of-sight range
using standard supplied ½ wave antennas
Selectable 1, 10, and 20 mW
transmitter RF output power (comparable to 5 times the analog RF output
power equivalent)
For ease of use, optimised
scanning automatically finds, prioritises, and selects the cleanest
frequencies available.
*Note that
ULXD4, ULXD6 and ULXD8 remain available for operation on legacy frequency bands
Scalable, Intelligent Hardware
Single (half-rack), Dual, and
Quad (full-rack) receiver form factors for any size installation
AES-256 bit encryption equipped
for secure wireless transmission
Ethernet networking allows for
streamlined setup across multiple receivers.
Wireless Workbench 6: The ULX-D
is compatible with Wireless Workbench 6 software for advanced frequency
coordination, monitoring, and control.
Comprehensive 3rd party control
and monitoring across subnets
AXT600
Axient® Spectrum Manager compatibility
Rugged metal housing on both
transmitters and receiver
Dual and Quad receivers
additionally feature:
Expanded tuning range (up to
166 MHz, region dependent)
RF cascade ports, internal
power supply, and dual Ethernet ports
Dante™ digital networked audio
over Ethernet
Bodypack frequency diversity
ensures uninterrupted audio for mission-critical applications
Audio summing routes audio
signal to multiple outputs
Shure Advanced Power Management
SB900 Series rechargeable
batteries provides ULX-D transmitters with up to 12 hours of run-time use
Lithium-Ion chemistry and
intelligent Shure battery circuitry for precision metering and zero memory
effect saving the equivalent of 1000 disposable batteries
Transmitters and receivers
display remaining battery life in hours and minutes, accurate to within 15
minutes.
