Allen & Heath QU-6 Digital Mixer 38 In/24 Out

Features

Processing & FX

• 96kHz XCVI Core
• 6 Multi-FX Engines with dedicated Stereo Returns
• DEEP Processing Ready

Mix Architecture

• 38 Inputs to Mix (32x Mono/Linkable, 3x Stereo)
• 12 Mixes (6 Mono/Linkable Aux/Group, 6 Stereo Aux/Group)
• 4 Mono/Linkable Matrix
• Stereo Main LR Output

I/O

• 24 XLR/Jack ‘Combi’ Mic/Line Input Sockets
• 2 Stereo Line Input Sockets (each 2x TRS)
• 16 XLR Output Sockets
• 1 XLR Talkback Socket
• 2 TRS Output Sockets
• 1 AES3 Stereo Digital Output Socket
• 128?128 Intelligent SLink Port for Everything I/O expansion and system connections
• 16?16 48/96 kHz Dante interface with dedicated locking EtherCon port (Qu-6D only)
• Stereo Headphone Output

Control

• 7” Capacitive Touchscreen
• 25 100mm Motorised Faders
• 4 Channel Strip Layers
• Remote control via free apps – Windows/MacOS/iOS/Android
• 8 SoftKeys
• Configurable single/dual Footswitch Connection

Recording & Playback

• USB-A For stereo audio record/playback and data transfer
• USB-C Audio interface for multichannel record/playback (32?32)
• SD Card Slot for multichannel audio recording or playback (16?16@96kHz, 32?32@48kHz)

Misc

• 12V Lamp Socket
• Configurable Chromatic Channel Meter LED’s
